The 5P package consists of all necessary materials for the so-called "vertical flow-through constructed wetland", for a household of 4 to 5 people.

The price is € 6,025.00 and this includes VAT and the transport to your plot.

In addition to the materials, the package includes a comprehensive construction manual.

It not only describes how to make it, it also tells you how (and why) a helophyte filter works.

There is also an extensive parts list, arranged per supplier (so that you can quickly check per supplier whether everything is correct). And a parts list per facet of the construction phase (so that you know exactly which part belongs where).

Naturally, the package also includes detailed construction drawings for your system.

Finally, there is also a manual for the use of a helophyte filter, including tips on what to use and what not. (The latter list is very limited, a constructed wetland is also entirely suitable for very ordinary people :-), we do not expect strange things from you!)

Finally, you will also find in the manual all information about the annual maintenance of the entire treatment system. You can do that yourself, but you can also outsource it to us, after which you will also receive a clear report on the state of all aspects, tips, etc.

And many of the questions you may have will be answered below - and otherwise under the heading "Frequently asked questions about the DIY kits, on the page called" How ".

Package 5P

cap .: for 4-5 persons

price: € 6,025.00 (incl. VAT)

contains:

1 pre-settling tank 4.0 m³

1 pumping station 1.5 m³

reed size:

long: 4.78 m

wide: 3.14 m

surface: 15.00 m²

cont .: 15.00 m³

high: 0 cm above ground level.

With the top, the filter is therefore equal to ground level. This means that, due to the excavation work, approximately 21 m³ of soil remains with this work. Please take this into account, it may be processed on your own site.

The following are included in the route from the waste water to the filter:

• free-fall pipes 110 and 75 mm Ø (environmentally friendly material, with KOMO approval, for the separate discharge of gray and black waste water (for the distances below) between the components, including:

• 2 unblocking points at the house!

• discharge pipes for evenly distributing the waste water over the filter

• drainage pipe for collecting the purified water

• all necessary couplings and bends, in accordance with the construction drawing

• pre-settling tank made of concrete, not traffic-resistant

• concrete pumping station, not traffic-bearing

• the sinks are supplied with elevation and real cast iron lids

• solid, energy-efficient submersible pump with vortex impeller

• pump control, complete with pulse and hour meter and alarm signaling for power failure and overflow, including housing

• waterproof, environmentally friendly foil for the filter, as well as the

• root cloth and protective cloth

• gravel, for drainage and top layer (in big bags)

• filter substrate, complete with

• special coarse sand for the finishing layer (in big bags)

• iron and lime to meet the 3B class

• reed plants (we supply 10 plants per m²!)

• inspection pit for possible sampling and to be able to assess the quality yourself, the cleaned water is discharged into the ditch

• the transport of the above materials

• a very extensive manual, not only about the construction but also about the use and maintenance.

The package contains enough piping to cover the following distances:

• 5 m. Distance between housing and pre-settling tank

• 2 m. Between settling tank and pumping station

• 2 m. From pumping station to ditch

• 1 m. From pumping station to the reed bed

• 2 m. From rietveld to the ditch, for discharging the cleaned water

Not included are:

• Ground cable between housing and control box.

• Straw bales for the filter (1 piece, the application of this is advised, it is not mandatory).

• Excavator: you must arrange this yourself.

• The required labor. You must supply this yourself.

You can think of construction time in workable days about 3½ days, based on two skilled persons and the excavator.

We can offer construction supervision by one of our professionals. This can be ordered per day (of course only by appointment).

The rate for this, excluding travel costs and including VAT, is € 695.00 per day.

Optional:

• If your situation leads to different distances, the necessary piping can be supplied at an additional cost, per 5 m length. Are you thinking of ordering extra sleeves and bends in that case?

• Likewise, pits can be supplied that are subject to traffic loads.

• The sedimentation pit can be replaced by a separate septic tank and grease trap.

• Even if you want to reuse the purified water for toilet flushing or irrigation, for example, we have the right solution for you.

This is an extensive package with a lot of information, errors in the text are not excluded and prices of the materials and services change regularly. Deviations are therefore possible and the above text is therefore indicative, but not binding.

PS: These kits are only available in the Netherlands.

The 8P package consists of all necessary materials for the so-called "vertical flow-through helophyte filter", for a household of 6 to 8 people.

The price is € 7,800 and this includes VAT and the transport to your plot.

In addition to the materials, the package includes a comprehensive construction manual.

It not only describes how to make it, it also tells you how (and why) a helophyte filter works.

There is also an extensive parts list, arranged per supplier (so that you can quickly check per supplier whether everything is correct). And a parts list per facet of the construction phase (so that you know exactly which part belongs where).

Naturally, the package also includes detailed construction drawings for your system.

Finally, there is also a manual for the use of a helophyte filter, including tips on what to use and what not. (The latter list is very limited, a helophyte filter is also entirely suitable for very ordinary people :-), we do not expect strange things from you!)

Finally, you will also find in the manual all information about the annual maintenance of the entire treatment system. You can do that yourself, but you can also outsource it to us, after which you will also receive a clear report on the state of all aspects, tips, etc.

And many of the questions you may have will be answered below - and otherwise under the heading "Frequently asked questions about the DIY kits, on the page called" How ".

Package 8P

cap .: for 6-8 persons

price: € 7,800 (incl. VAT)

contains:

2 pre-settling tanks of 3.0 m³

1 pumping station 1.5 m³

reed size:

long: 7.64 m

wide: 3.14 m

surface: 24.00 m²

cont .: 24.00 m³

high: 0 cm above ground level.

With the top, the filter is therefore equal to ground level. This means that, due to the excavation work, approximately 32 m³ of soil remains with this work. Please take this into account, it may be processed on your own site.

The following are included in the route from the waste water to the filter:

• free-fall pipes 110 and 75 mm Ø (environmentally friendly material, with KOMO approval, for the separate discharge of gray and black waste water (for the distances below) between the components, including:

• 2 unblocking points at the house!

• discharge pipes for evenly distributing the waste water over the filter

• drainage pipe for collecting the purified water

• all necessary couplings and bends, in accordance with the construction drawing

• pre-settling tank made of concrete, not traffic-resistant

• concrete pumping station, not traffic-bearing

• the sinks are supplied with elevation and real cast iron lids

• solid, energy-efficient submersible pump with vortex impeller

• pump control, complete with pulse and hour meter and alarm signaling for power failure and overflow, including housing

• waterproof, environmentally friendly foil for the filter, as well as the

• root cloth and protective cloth

• gravel, for drainage and top layer (in big bags)

• filter substrate, complete with

• special coarse sand for the finishing layer (in big bags)

• iron and lime to meet the 3B class

• reed plants (we supply 10 plants per m²!)

• inspection pit for possible sampling and to be able to assess the quality yourself, the cleaned water is discharged into the ditch

• the transport of the above materials

• a very extensive manual, not only about the construction but also about the use and maintenance.

The package contains enough piping to cover the following distances:

• 5 m. Distance between housing and pre-settling tank

• 2 × 3 m. Between settling tank and pumping station

• 2 m. From pumping station to ditch

• 0.4 m. From pumping station to the reed bed

• 8 m. From rietveld to the ditch, for discharging the cleaned water

Not included are:

• Ground cable between housing and control box.

• Straw bales for the filter (2 pieces, the application of which is advised, it is not mandatory).

• Excavator: you must arrange this yourself.

• The required labor. You must supply this yourself.

Think about construction time in workable days, about 4½ days, assuming two skilled persons and the excavator.

We can offer construction supervision by one of our professionals. This can be ordered per day (of course only by appointment).

The rate for this, including travel costs and VAT, is € 695 per day.

The prices mentioned are of course subject to periodic price increases from our suppliers.

Optional:

• If your situation leads to different distances, the necessary piping can be supplied at an additional cost, per 5 m length. Are you thinking of ordering extra sleeves and bends in that case?

644/5000

• Likewise, pits can be supplied that are subject to traffic loads.

• The sedimentation pit can be replaced by a separate septic tank and grease trap.

• Even if you want to reuse the purified water for toilet flushing or irrigation, for example, we have the right solution for you.

This is an extensive package with a lot of information, errors in the text are not excluded and prices of the materials and services change regularly. Deviations are therefore possible and the above text is therefore indicative, but not binding.

PS: these kits are only available in the Netherlands

The Tiny wetland is our latest development, inspired by and developed for Tiny House owners.

The Mobile Constructed Wetland is an artificial swamp in a waterproof container, which is used to purify urine (compost toilet), waste water from the kitchen, shower and washing machine.

With a properly functioning helophyte filter, it is in principle permitted to discharge purified waste water into the surface water or soil.

This Vertical Flow Constructed Wetland is a system in which the waste water is fed vertically through a filter package via supply and discharge pipes. The filter can be used above ground, partially buried or completely in the ground.

The particulars of the filter:

The mobile Constructed Wetland is a project of TinyStee, specialist in Tiny Houses and ECOFYT. Together we have developed a mobile water treatment on a small scale, the Tiny Wetland. This unique helophyte filter has many advantages:

• Easily movable, for example to a different residential location
• Natural flow, without pump (no electricity required)
• No maintenance costs, no sludge disposal costs
• Largely made from recycled material and long life
• Equipped with grease separator to prevent silting
• Water distribution system
• Inspection pit
• Water level control

The Duo version has been developed to purify the grey water of a 1 person household, the Trio version is for the gray water of a two person household.

Tiny houses often have a compost toilet, which is why we did not include the toilet water in these designs.

The duo version costs € 1,495.00 including VAT and is delivered free of charge. For the trio version this is € 1,725.00

(Prices for sending in the Netherlands only)

You still have to buy sand yourself (we will tell you exactly what you need), after which you can assemble the filter yourself, with all the supplied materials.
